Nycote 88
Nycote® 88 is one of our flagship coatings that can be applied to substrates that need protection from corrosion, electrical conduction and friction. It comes in an easy-to-use two-part component. Combining the two components results in a three-hour window before the formula begins to set.
/Product%20Page%20Assets/Artboard%201.webp?width=435&height=450&name=Artboard%201.webp "Artboard 1")
Easy Application for Strong Protection
Nycote® 88 is a two-part coating designed to protect substrates from corrosion, electrical conduction, and friction, with a three-hour working time after mixing. Apply Nycote 88 by brush, spray, dip, or roll-on method to substrates that require protection from aircraft fuels, oil, lubricants, phosphate ester hydraulic fluids, salt spray and water. Nycote® 88 also provides excellent high impact, abrasion resistance, flexibility and toughness at temperatures of -70°F to +400°F (-57°C to +149°C).
Product Details
Product Specifications
+| Physical properties [Temperature Range from -70°F to +300°F (-56°C to 148°C)] | Resin | Film |
|---|---|---|
| Viscosity: @ 72°F Zahn #2 Cup | 21-27Seconds | N/A |
| Solids Content (non-vol.) | 17% | N/A |
| Flash Point: C.O.C | 70°F | N/A |
| Pounds Per Gallon @ 78°F | 7.4±0.2 lb. | N/A |
| Shelf Life @ 78°F | 12 Months | N/A |
| Film Thickness, 1 Dipcoat | N/A | 0.4 mil |
| Coverage Per Gallon | 300 sq. ft. | N/A |
| Tack-Free Time, 50% RH @ 70°F | N/A | One Hour |
| Film Pencil Hardness | N/A | 1-H |
| Adhesion (peel-test value) | N/A | 21 lbs., per inch |
| Abrasion Resistance – (500 Gr. #17 wheel 100 cycles) | N/A | 2.9 mgm |
| Airbus Fuel Resistance to ISO 1817 – No separation or cracks of ID Labels | N/A | Pass |
| Color shade to ASTM 4471 & Airbus spec (DAN1172/1174) Transparent liquids | N/A | Pass |
| Airbus DI Water Resistance – Pass noseparation or cracks on ID | N/A | Pass |
| Sheer Strength | N/A | > 3.9 |
| Elongation Break | - | > 200 |
| Heat Force Cure * Always check with your own internal engineering department to ensure materials you intend to force cure can withstand the temperatures listed on the Nycote table | - | 2-HR |
| ASTM 2832 – Solids Content Non-volatile | Pass | N/A |
| UVB @300 hours Resistant to ASTMG154-No degradation of the coating /Nylon will yellow slightly over time | - | Pass |
| Evaluation of ASTM D5264 standard Sutherland Rub testing to gauge the amount of scuffing or abrasion caused during shipping, handling, and storage. TEST REPORT: SN 2206163 Rev. 01 | - | - |
Fluid Resistance
+| Fluid Resistance – 30 days immersion @ 75°F | |
|---|---|
| JP-4 | Excellent |
| JP-5 | Excellent |
| JP-8 | Excellent |
| JP-10 | Excellent |
| Kerosene | Excellent |
| Gasoline | Excellent |
| Skydrol® | Excellent |
| 100% RH @120°F | Excellent |
| Distilled Water | Excellent |
| Tap Water | Excellent |
| Salt Spray | Excellent |
| 80% JP-4 Bacteria Laden Distilled Water | Excellent |
| H2O Immersion Composite (Submersed 7 days)** | Excellent |
| H2O Immersion Metal** | Excellent |
| Potassium Formate Submersion 24-hours | Excellent |
| Potassium Acetate Submersion 24-hours | Excellent |
Adhesion Characteristics
+| Untreated Aluminum | Excellent |
| Chem-filmed (Irridited) Aluminum | Excellent |
| Anodized Aluminum | Excellent |
| Stainless Steel | Excellent |
| Fiberglass | Excellent |
| Zinc Chromate Primed Aluminum | Excellent |
| Any Metal Surface | Excellent |
| Glass | Excellent |
| Carbon Composites / Tin / Vinyl | Excellent |
| PTFE / Viton / TPU | Excellent |
| Adhesion measuring by adhesion tape testJAW ISO 2409 Dry Test Classification(0 indicates best performance on a scale f 0-3)** | Result 0 |
Special Properties
+| ISO22196 Coating efficacy to microorganisms S. Aureus ACCT6538 & E. Coli ACCT9739.Effectively kills microbes. | 99.99003% Kill |
| Permeation Testing to: | MIL-DTL-5578D Aircraft Fuel Tanks Self Sealing;MIL-DTL-27422F Fuel Tank Crash & Ballistic Resistance;MIL-T-52983G Fuel Tanks Fabric Collapsible |
/Product%20Page%20Assets/fuel_hose.jpg?width=1200&height=1200&name=fuel_hose.jpg)
/Product%20Page%20Assets/copper_conductor.jpg?width=1200&height=1200&name=copper_conductor.jpg)
/Product%20Page%20Assets/Nycote88_LandingGear.webp?width=3376&height=6000&name=Nycote88_LandingGear.webp)
NSNs
+- 8010-01-530-5341
Storage Temperature Requirements
+- Store at 70°F (21°C). Keep away from fire or flame.
- Note: Ideal storage temperature is 70°F (21°C); acceptable storage range is between 65°F to 80°F (18.3°C to 26.7°C). Storing below 65°F (18.3°C) may cause cloudiness or gel; heat at 180°F (82°C) for two hours. This should restore the product to its normal liquid condition. If possible, re-verify viscosity with Zahn #2 cup (21-27 seconds).
- Nycote® 88 has a 12 month shelf life provided that the accelerator is not added to base product. Once the accelerator has been added, the formula has a three-hour application window before hardening process begins.
Cure Time Table
+Allow one to two hours air dry to become tack free. In dry air allow 72 hours at room temperature for full cure or:
- Heat twelve hours @ 120°F (49°C)
- Heat eight hours @ 150°F (66°C)
- Heat four hours @ 180°F (82°C)
- Heat two hours @ 220°F (105°C)
- Cure film temperature range is -70°F to +300°F (-57°C to 204°C) * Always check with your own internal engineering department to ensure materials you intend to force cure can withstand the temperatures listed on the Nycote table.
OEM Product Specifications / ASTM Testing Standards
+OEM/Specs:
- BS7225
- DMS1850
- DWG55135
- ESE RPT-7456-015
- FED-STD-141
- MC5014
- MC9014
- MIL-DTL-27422F
- MIL-DTL-5578D
- MIL-H-5606
- MIL-I-46058
- MIL-T-52983G
- NAS1611
- NAS1613
- PCS5157
- SAE-AMS-22725
- SAE-AMS-S-4383
- SAE AMS-S-8802
Standards:
- ASTM D445
- ASTM D1084
- ASTM D-1400
- ASTM D-1475
- ASTM 2832
- ASTM-B117-11
- ASTM D-1310
- ASTM D4060
- ASTM D471
- ASTM D7901
- ISO-1817
- ISO-9116
- Method 6192
- IPC-TM-650
